Experience compact yet powerful motion control with the Schneider Electric Lexium LXM28AU07M3X Servo Drive, part of the Lexium 28 series — designed for small to mid-range automation machinery, robotics, CNC units, packaging, and production lines. Reliable, flexible, and easy to integrate, this 0.75 kW servo drive offers high performance and straightforward installation for a wide range of industrial applications.
Key Features
- 0.75 kW (750 W) Output Power — sufficient for small to mid-level servo motors and light-to-medium loads
- Single- or Three-Phase 200–230 V Supply — compatible with common industrial power supplies
- Compact Housing (Lexium 28 range) — width 55 mm, depth 146 mm, height 150 mm — saves panel space
- Continuous Output Current 4.5 A at 16 kHz switching frequency — stable continuous operation
- 3‑Second Peak Output Current: 13.5 A at 220 V — allows for motor startup and transient loads
- Integrated Communication Interfaces: CANopen / CANmotion — simplifies integration with automation and motion control systems
- Spring-Terminal Power/Control Wiring & RJ45 Communication Ports — simplifies installation and wiring
- IP20 Enclosure — suitable for industrial control cabinets under standard environmental protection
Technical Specifications
| Specification | Details |
| Model / Series | LXM28AU07M3X — Lexium 28 servo drive |
| Continuous Output Power | 0.75 kW / 750 W |
| Supply Voltage | 200–230 V AC, single- or three-phase |
| Supply Voltage Range | 170…255 V (single-phase), 200…255 V (three-phase) |
| Supply Frequency | 50/60 Hz |
| Continuous Output Current | 4.5 A @ 16 kHz switching frequency |
| Peak Output Current (3s) | 13.5 A at 220 V |
| Cooling / Housing | Compact housing (Lexium 28), natural convection / integrated fan (depending on mounting/option) |
| Protection / Safety | Electrical isolation between power and control circuits; over-current/voltage protections per standard; meets EN/IEC 61800‑5‑1 norms |
| Dimensions (W × D × H) | 55 mm × 146 mm × 150 mm |
| Net Weight | ~1 kg |
| Enclosure / Protection Class | IP20 |
Applications
- Compact CNC machines and small-to-medium machine tools needing precise speed/position control
- Robotic arms, pick-and-place automation, and small robotic systems
- Packaging, printing, and labeling machines
- Conveyor systems, material handling, and assembly-line automation
- General industrial automation tasks requiring a compact, flexible, and reliable servo drive
